High Brightness Outdoor Rental LED Display SMD 2727 1/13 Scan Mode 38.5W
Product Description
1.High brightness Contrast:4000:1, which is a very high level to
ensure a vivid image of our LED display screen system
2. First-class LED chip to ensure the long lift-time and high
brightness of our LED display screen system
3.Clear vivid image quality even in direct, full-on sunlight to
ensure you attracts more audience
4.Long-term Brightness:More 7000-nit brightness(for outdoor full
color)(2000 nits brightness for indoor full color)capacity
throughout product lifetime of the LED display screen.
5.Easy Installation & Using: easy & simple installation interface
and user friendly software to ensure the user friendly interface of
the LED display screen system
6.Convenient Servicing: Front and rear cabinet access make the
maintance work very convenient and low cost.
OUTDOOR P4.81 SMD 3IN1 TECHNICAL PARAMETERS
| Unit Module | Item | Parameter |
| Model Number | SF-SS4.81-13S-A | |
| Module size | 250mm*250mm | |
| Pixel pitch | 4.81mm | |
| Pixels Density | 43264 dot/m2 | |
| Pixel configuration | 1R1G1B | |
| Package mode | Nationstar SMD2727 | |
| Pixel resolution | 52dots(W)*52 dots (H) | |
| Max Power | 38.5W | |
| Weight | 0.58kg | |
| Drive type | Constant drive | |
| Scan mode | 1/13 | |
| Port type | HUB75-A | |
| Brightness of white balance | ≥4850cd/m2 |
LED Cabinet | Dimension | 500mm*500mm |
| Monomer Module Number | 4pcs | |
| Power supply | 5V/60A*1pcs | |
| Thermal discharge | fan 2pcs | |
| Pixel per cabinet | 104mm*104mm | |
| Best viewing distance | 2M～14M | |
| Best viewing angle | 110°(W) 110°(H) | |
| Temperature | storage:-35℃～+85℃ working:-20℃～+50℃ | |
| Relative humidity | 10%-95% | |
| Thickness | 100mm |
| ower | Working voltage | AC110～220V±10% |
| Average Power consumption | 200W/㎡ | |
| Max Power consumption | <400W/㎡ | |
| Current | <20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | >1920HZ | |
| Grey scale/colors | 16384gray level/16.7M colors | |
| MTBF | >9000hours | |
| Power switch | Automatic switch | |
| Display Mode | ≥800*600/1024*768 |
|
|
