Professional LED Dispaly Manufacturer.
8 Years
| Ask Lasest Price | |
| Brand Name : | SOL COLUR |
| Model Number : | P1.5625 |
| Certification : | CE,ROHS,IP65 |
| Price : | Negotiable |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability : | 5000 Square Meter/Square Meters per Month |
| Delivery Time : | 15-20days |
P1.5625 Small Pixel Pitch LED Display Module Size 200mm*100mm High Antistatic
Product description
1. Die casting aluminum box with high precision ensures smooth and seamless screen body.
2. P1.5625 HD LED display screen uniform,Clear image and strong sense of hierarchy.
3. Low brightness, high ash, high antistatic and high refresh.
| Unit Module | Item | Parameter |
| Model Number | SF-TS1.5625-32S-A | |
| Module size | 200mm*100mm | |
| Pixel pitch | 1.5625mm | |
| Pixels Density | 10000dots/m2 | |
| Pixel configuration | 1R1G1B | |
| Package mode | SMD1010 | |
| Pixel resolution | 128ots(W)*64 dots(H) | |
| Max Power | 25W | |
| Module thickness | 14.75mm | |
| Weight | 0.4kg | |
| Drive type | Constant drive | |
| Scan mode | 1/32 | |
| Port type | HUB75-A | |
| Brightness of white balance | ≥1000cd/m2 | |
LED Cabinet | Dimension | 400mm*300mm |
| Monomer Module Number | 16pcs | |
| Power supply | 5V/60A*1pcs | |
| Thermal discharge | fan 1pcs | |
| Pixel per cabinet | 256mm*192mm | |
| Best viewing distance | 2.5M～10M | |
| Best viewing angle | 140°(W)140°(H) | |
| Temperature | storage:-35℃～+85℃ working:-20℃～+50℃ | |
| Relative humidity | 10%-95% | |
| Thickness | 85mm | |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | 500W/㎡ | |
| Max Power consumption | ≤1250W/㎡ | |
| Current | ≤20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | ≥1920HZ | |
| Grey scale/colors | 4096gray level/16.7M colors | |
| MTBF | ≥10000hours | |
| Power switch | Automatic switch |
|
|
